Description

Product details

The provided image outlines the technical specifications for industrial Wire Mesh, which is used across processing industries for filtration, separation, screening, grading, and structural reinforcement. ## ⚙️ Technical Specifications## Sizing & Geometry * Wire Diameter: 0.08 mm to 5 mm (From ultra-fine micro-filtration wires up to thick, heavy-duty screening barriers). * Wire Opening: Configurable based on Mesh Number (number of openings per linear inch) or exact Clear Opening (the physical distance between adjacent wires). * Shape Configurations: Customized width and length dimensions tailored to equipment sizing. * Supply Quantities: Available as individual cut-to-size pieces, continuous rolled stock, or pre-framed screens. ------------------------------ ## 📋 Material & Structural Construction## 1. Material Alloys * Stainless Steel: Provides exceptional corrosion resistance, longevity, and hygienic properties for food, pharma, and chemical processing lines. * Carbon Steel: Offers cost-effective strength for heavy-duty sorting, aggregate screening, and protective fencing. * Alloy Steel: Engineered to withstand specialized high-temperature or highly abrasive environments. ## 2. Mesh Construction Types * Welded Mesh: Wires are cross-laid and electrically resistance-welded at each intersection, providing high rigid structural stability and precise grid alignment. * Woven Mesh: Wires are interwoven over and under each other on a loom, offering flexibility and finer filtration profiles. * Note: Orders should state the specific weave pattern desired (e.g., Plain Weave, Twill Weave, or Dutch Weave for fine micronic filtering). * Special Fabrication: Custom finishing options like edged borders, reinforced hems, or circular screen stamping can be accommodated based on drawing prints. ------------------------------ If you are setting up a filtration loop or screening system, I can help you calculate the open area percentage for a specific mesh size, check the micron rating equivalent, or assist in sourcing custom woven screens from industrial suppliers. What technical details can I help you evaluate next?
