Stainless Steel Zero Dead Leg (ZDL) Diaphragm Valves, configured here into a modular, multi-port manifold assembly.⚙️ Design & FunctionalityZero Dead Leg Design: These valves are engineered specifically to eliminate “dead legs”—areas in a piping system where fluid can stagnate, trap bacteria, and cause contamination.Diaphragm Seal: A flexible internal diaphragm acts as the dynamic seal. It completely isolates the fluid path from the valve's mechanical parts (the stem and bonnet), ensuring ultimate purity.Sanitary Tri-Clamp Connections: Every inlet, outlet, and downspout port features a flanged tri-clamp end. This allows for rapid, tool-free breakdown, cleaning, and sanitizing.💡 Common ApplicationsBecause of their crevice-free, ultra-clean design, these manifolds are critical components in industries with strict hygiene requirements:Pharmaceutical WFI Systems: Distribution loops for Water-for-Injection (WFI) and purified water.Biotech Processing: Sampling, harvesting, and routing sensitive biological batches.Cosmetics & Food Production: Handling sterile ingredients where batch-to-batch contamination must be avoided.Would you like to know how to properly position these for optimal self-draining to meet ASME BPE standards, or do you need help selecting replacement diaphragm materials (like EPDM or PTFE)?
