Description
Product details
Materials: Typically constructed from high-grade 304 (CF8) or 316 (CF8M) Stainless Steel for extreme corrosion resistance and durability.Seals: Available in PTFE (Teflon), FKM (Viton), or EPDM depending on temperature and chemical requirements.Size Range: Commonly ranges from compact 1/4“ to larger 4” diameters.Pressure Ratings: Standards typically range from 200 PSI to 1,000 PSI WOG (Water, Oil, Gas), with specialized heavy-duty industrial valves handling up to 6,000+ PSI.Temperature Range: Operates fluidly in extremes, often rated from -60°F to 450°F (-51°C to 232°C).End Connections BRAND NAME Jayshree STAINLESS STEEL VALVES SIZE 1/8“ TO 2” / 6 MM TO 50 MM CONNECTION THREADED, TUBE END, SOCKET WELD END, FLANGE END THREADS NPT, BSPP, BSPT, METRIC, JIC, UNF STAINLESS STEEL VALVES FLOW PATTERN STRAIGHT BODY SHAPE HEXAGON STAINLESS STEEL VALVES PRESSURE RATING 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI, 20000 PSI CRACKING PRESSURE 0.5 BAR ORIFICE SIZE 2 MM TO 40 MM STAINLESS STEEL VALVES TYPE POPPET TYPE, SPRING TYPE MEDIA HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL MEDIA TEMPERATURE (-50* C TO 350*C ) RANGE AS PER PRESSURE STAINLESS STEEL VALVES BODY TYPE BAR STOCK, FORGED PACKING DETAILS BOX PACKING, WOODEN PALLET EQUIVALENT BRANDS SWAGELOK, PARKER, STAUFF, DK-LOK, HAMLET, OLIVER VALVES, HOKE STAINLESS STEEL VALVES MATERIAL SS 304, SS 304L, SS 316, SS 316L, SS 316 TI, SS 321, SS 347
