## Overview of Stainless Steel Victaulic® Fittings Stainless steel grooved Victaulic® style fittings offer fast, reliable, and leak-free joint connections for demanding high-pressure and corrosive piping environments. ## Material & Surface Finish * Grades: Premium quality SS 304 and SS 316 * Casting Standards: ASTM A351 / A743 * Surface Treatment: Pickled and passivated for superior corrosion resistance ## Operating Specifications * Available Sizes: 1/2' to 24' (DN15 to DN600) * Pressure Ratings: Up to 300 PSI (depends on component size and application) * Working Temperature: -34°C to +121°C (-29°F to +250°F) * Compliance Standards: ASME B31.1, B31.3, B31.9 | UL / FM Approved | NSF / ANSI 61 Certified ## Sealing & Gasket Options * EPDM: Standard option for general water and dilute acid service * NBR (Nitrile): Ideal for petroleum products, oils, and air systems * FKM (Viton™): High-temperature and superior chemical resistance * Silicone: Excellent for food-grade, pharmaceutical, and high-temp clean environments ## Types of Fittings Displayed * Couplings: Rigid & Flexible Couplings, Reducing Couplings, Flexible Reducing Couplings * Elbows: 90° Elbow, 45° Elbow * Tees: Standard Tee, Reducing Tee * Adapters & Flanges: Flange Adapter, Wall Flange, Threaded Adapter, Grooved End Adapter * End Closures: Concentric Reducer, Cap * Hardware: Pipe Clamp, Gaskets ## Target Industries * Fire protection and HVAC systems * Municipal water supply and chemical processing * Food, beverage, and pharmaceutical manufacturing * Marine, shipbuilding, pulp, paper, and power generation plants If you are designing or sourcing for a piping project, let me know: * Your preferred stainless steel grade (304 vs 316) * The nominal pipe size (DN/NPS) required * The chemical properties or temperature of your process media I can help clarify which gasket compound or coupling type matches your system requirements.
This is your website preview.
Currently it only shows your basic business info. Start adding relevant business details such as description, images and products or services to gain your customers attention by using Boost 360 android app / iOS App / web portal.
Stainless Steel Victaulic Fittings Manufacture And Supply In Ahmedabad
2026-06-09T11:52:18
## Overview of Stainless Steel Victaulic® Fittings Stainless steel grooved Victaulic® style fittings offer fast, reliable, and leak-free joint connections for demanding high-pressure and corrosive piping environments. ## Material & Surface Finish * Grades: Premium quality SS 304 and SS 316 * Casting Standards: ASTM A351 / A743 * Surface Treatment: Pickled and passivated for superior corrosion resistance ## Operating Specifications * Available Sizes: 1/2' to 24' (DN15 to DN600) * Pressure Ratings: Up to 300 PSI (depends on component size and application) * Working Temperature: -34°C to +121°C (-29°F to +250°F) * Compliance Standards: ASME B31.1, B31.3, B31.9 | UL / FM Approved | NSF / ANSI 61 Certified ## Sealing & Gasket Options * EPDM: Standard option for general water and dilute acid service * NBR (Nitrile): Ideal for petroleum products, oils, and air systems * FKM (Viton™): High-temperature and superior chemical resistance * Silicone: Excellent for food-grade, pharmaceutical, and high-temp clean environments ## Types of Fittings Displayed * Couplings: Rigid & Flexible Couplings, Reducing Couplings, Flexible Reducing Couplings * Elbows: 90° Elbow, 45° Elbow * Tees: Standard Tee, Reducing Tee * Adapters & Flanges: Flange Adapter, Wall Flange, Threaded Adapter, Grooved End Adapter * End Closures: Concentric Reducer, Cap * Hardware: Pipe Clamp, Gaskets ## Target Industries * Fire protection and HVAC systems * Municipal water supply and chemical processing * Food, beverage, and pharmaceutical manufacturing * Marine, shipbuilding, pulp, paper, and power generation plants If you are designing or sourcing for a piping project, let me know: * Your preferred stainless steel grade (304 vs 316) * The nominal pipe size (DN/NPS) required * The chemical properties or temperature of your process media I can help clarify which gasket compound or coupling type matches your system requirements.
