Grooved pipe fittings are modular mechanical components used to join pipes quickly without welding or threading. They conform to standards like ANSI/AWWA C606, feature Victaulic Grooved Fittings dimensions, handle pressures up to 500–750 PSI, and use ductile iron or stainless steel housings with rubber gaskets. Materials & Construction • Housings: Ductile iron conforming to ASTM A536 or CF8M stainless steel. • Finishes: Standard red or orange enamel paint; optional hot-dipped galvanized coating. • Sizes: Range from ¾ inch to 24 inches (DN20 to DN600) nominal pipe size. Gasket Specifications • Design: C-shaped pressure-responsive rubber gasket that seals tighter as internal pressure rises. • EPDM (Grade E): Green stripe code; rated for water from -30°F to 230°F (-34°C to 110°C), standard for fire protection. • Nitrile (Grade T): Orange stripe code; rated for oil products and air with oil. Pressure & Compliance Standards • Working Pressure: Up to 500 PSI (34 bar) or 750 PSI (52 bar) depending on coupling type and wall thickness. • Certifications: Frequently UL Listed and FM Approved for fire safety and industrial fluid systems. • Dimensional Standard: Complies with ANSI/AWWA C606 for roll and cut groove profiles. If you need specific details, please let me know:What pipe size and material are you using?Is this for fire protection, HVAC, or plumbing?
This is your website preview.
Currently it only shows your basic business info. Start adding relevant business details such as description, images and products or services to gain your customers attention by using Boost 360 android app / iOS App / web portal.
Grooved Fittings Stockist And Supplier In Ahmedabad Gujarat India
2026-08-15T18:32:32
Grooved pipe fittings are modular mechanical components used to join pipes quickly without welding or threading. They conform to standards like ANSI/AWWA C606, feature Victaulic Grooved Fittings dimensions, handle pressures up to 500–750 PSI, and use ductile iron or stainless steel housings with rubber gaskets. Materials & Construction • Housings: Ductile iron conforming to ASTM A536 or CF8M stainless steel. • Finishes: Standard red or orange enamel paint; optional hot-dipped galvanized coating. • Sizes: Range from ¾ inch to 24 inches (DN20 to DN600) nominal pipe size. Gasket Specifications • Design: C-shaped pressure-responsive rubber gasket that seals tighter as internal pressure rises. • EPDM (Grade E): Green stripe code; rated for water from -30°F to 230°F (-34°C to 110°C), standard for fire protection. • Nitrile (Grade T): Orange stripe code; rated for oil products and air with oil. Pressure & Compliance Standards • Working Pressure: Up to 500 PSI (34 bar) or 750 PSI (52 bar) depending on coupling type and wall thickness. • Certifications: Frequently UL Listed and FM Approved for fire safety and industrial fluid systems. • Dimensional Standard: Complies with ANSI/AWWA C606 for roll and cut groove profiles. If you need specific details, please let me know:What pipe size and material are you using?Is this for fire protection, HVAC, or plumbing?
2026-08-15T18:32:32
Submit Your Enquiry
